- Kết hợp giao diện có sẵn bao gồm: - usb2.0, serial và Ethernet - Usb2.0 và Parallel Thiết kế mạnh mẽ và ổn định cơ chế, đồ bên lâu dài
- Độ phân giải: 300dpi
Ứng dụng:
G530 lý tưởng cho các loại phương tiện in ấn nhiều như: - Sản phẩm nhiều, serial, theo dõi tài sản, in nhãn hạn sử dụng, túi, đồ trang sức, vải...
Thông số kỹ thuật:
Thông số kỹ thuật: - truyền nhiệt/ nhiệt trực tiếp - Độ phân giải: 300dpi( 12dots/mm) - Tốc độ in: 4ips ( 102mm/s) - Chiều rộng khổ in: 4.16"( 105.7mm) - Chiều cao nhãn in: min 0.16"(4mm), max 68"( 1727mm) - Bộ nhớ: 4MB Flash( 2MB sử dụng lưu trữ) /16MBSDram - Sensor: sensorđiều chỉnh. sensorcốđịnh - Ribbon: Wax, wax/resin, resin( 300m)
Thông số chi tiết
Print Method
Thermal Transfer / Direct Thermal
Resolution
300 dpi (12 dots/mm)
Print Speed
4IPS (102 mm/s)
Print Width
4.16" (105.7 mm)
Print Length
Min. 0.16” (4 mm)**; Max. 30” (762 mm)
Processor
32 Bit RISC CPU
Memory
8MB Flash (4MB for user storage) / 16MB SDRAM
Sensor Type
Adjustable reflective sensor. Fixed transmissive sensor, central aligned
Media
Types: Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming Width: 1” (25.4 mm) Min. - 4.64” (118 mm) Max. Thickness: 0.0024” (0.06 mm) Min. - 0.01” (0.25 mm) Max. Label roll diameter: Max. 5” (127 mm) Core diameter: 1”, 1.5”, 3" (25.4 mm, 38.1 mm, 76.2 mm)
Ribbon
Types: Wax, wax/resin, resin Length: 981’ (300 m) Width: 1.18” Min - 4.33” (30 mm - 110 mm) Max Ribbon roll diameter.: 2.67“ (68 mm) Core diameter: 1” (25.4 mm)
Printer Language
EZPL, GEPL, GZPL auto switch
Software
Label design software: GoLabel (for EZPL only) Driver: MAC , Linux Windows 2000 / XP / VISTA / Windows 7 / Windows 8.1 DLL: Win CE , .NET , Windows Mobile, Windows 2000 / XP / VISTA / Windows 7 / Windows 8.1 / Android
Resident Fonts
Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Bitmap fonts 8 times expandable in horizontal and vertical directions TTF fonts:CG Triumvirate™ (Bold / Italic / Underline). 0°, 90°, 180°, 270° rotatable
Download Fonts
Bitmap fonts: 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable Asian fonts: 16x16, 24x24. Traditional Chinese (BIG-5), Simplified Chinese(GB2312), Japanese (S-JIS), Korean (KS-X1001)90∘,180∘,270∘, rotatable and 8 times expandable in horizontal and vertical directions TTF fonts: 90°, 180°, 270° rotatable
Barcodes
1-D Bar codes: Code 39, Code 93, EAN 8/13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code 128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5 , Logmars, Code 11, Code 49, Cadablock 2-D Bar codes: PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec code
